Del Sol Valley · Retro's Villa
Smart Villa
Network Topology
Network Topology
A fully managed Wi-Fi 7 mesh on structured Cat 6A backbone — 33-camera Hikvision + UniFi Protect estate, 4-gateway SuperLink sensor mesh, 10-VLAN segmented LAN, dual-WAN with Starlink failover, NORD VPN policy routing and KNX automation — engineered, deployed and monitored end-to-end by QSN.
10
UniFi Switches
+ 1 UDM PRO
22
Access Points
13 Wi-Fi 7 · 9 Wi-Fi 6
33
IP Cameras
31 HIK · 2 UP G6
4
SuperLink GWs
SENSOR MESH
10
VLANs · 7 SSIDs
SEGMENTED
100+
Total Endpoints
CAT 6A · 10 GbE
Layer 0 — Dual-WAN Edge · VPN Clients · Policy-Based Routing
⇲ Internet (2) · Dual-WAN
DU internet
DU Telecom · Primary
DU.DU.DU.DU
Starlink
LEO Backup · Roaming PBR
SL.SL.SL.SL
DEL SOL VALLEY
UDM PRO · DREAM MACHINE
Default · 10.10.0.0/24
⌖ VPN Client (2) · OpenVPN
NORD VPN NEW
OpenVPN · Active
VPN.VPN.VPN.VPN
NORD VPN USA
OpenVPN · Standby
— idle —
Policy-Based Routing (3)
WAN Steering · Traffic Selectors
⌖ NORD VPN · Specific Traffic
Match: Region · 2 Sources
→ NORD VPN NEW
⇄ Normal Traffic · All Traffic
Match: All Devices
→ DU Internet (default)
🛰 Starlink Override · All Traffic
Match: Starlink VLAN
→ Starlink WAN
Networks (10) · VLAN Segmentation
Del Sol Valley UDM Pro
Default
untagged · MGMT
10.10.0.0/24
Automation
VLAN 40 · KNX/IoT
192.168.40.0/26
Guest
VLAN 11 · isolated
192.168.11.0/27
HOME
VLAN 20 · trusted
192.168.20.0/24
IoT
VLAN 7 · smart-home
192.168.7.0/24
Music Server
VLAN 30 · audio
192.168.30.0/26
Staff
VLAN 8 · filtered
192.168.8.0/27
Starlink
VLAN 10 · WAN-pinned
192.168.10.0/24
Surveillance
VLAN 4 · cameras
192.168.4.0/24
USA
VLAN 2 · NORD US
192.168.3.0/28
Wi-Fi (7) · SSID Map
Wi-Fi 7 + Wi-Fi 6 · 22 APs
Retro 2.4Ghz
2.4 GHz
→ HOME
All APs
Retro 5/6
5 / 6 GHz
→ HOME
All APs
Retro IOT
2.4 GHz
→ IoT
All APs
Retro USA
2.4 GHz
→ USA
All APs
Retro_Gst
5 GHz
→ Guest
20 APs
Retro Staff
2.4 / 5 GHz
→ Staff
All APs
SL_Retro
6 / 5 GHz
→ Starlink
19 APs
Layer 1 — Core Distribution (USW Pro Max 24 PoE · 10 GbE)
USW 1 PRO MAX · Core A
USW Pro Max 24 PoE
10 GbE UPLINK
Hikvision Cameras · FE PoE
Hik Stn 5D1 Main OutdoorD21 SPA FloorD31 IT RoomD14 ElectricalD10 GardenD30 OutsideD7 Garage
UniFi Protect Cameras · G6 Bullet
▣ UP Cam 1 Main▣ UP Cam 2 Garage
Hikvision PoE Hubs
Hik Sub-Hub AHik Sub-Hub B
Direct Access Points
AP 1F BED 1
U7 LONG-RANGE
AP 1F L-L
U6 LITE
KITCHEN
U6 IW
GARAGE AREA
U6 MESH
USW 3 · 24 PoE
USW 24 PoE
GbE uplink
Hik IoT HubCasa ServerHik NVRDayton Audio 6×6
USW ULTRA · OD Service Bldg
USW Ultra
GbE uplink
AP OD ROOM 1
U6 PRO
AP OD ROOM 2
U6 LR
USW FLEX · 1F L-L (Bedroom)
USW Flex
GbE uplink
D17 BedroomD18 BedroomD19 Bedroom
AP 1F BED 2
U7 LONG-RANGE
AP 1F BED 3
U7 LONG-RANGE
AP 1F MASTER BED 1
U7 PRO WALL
AP 1F MASTER BED 2
U6 MESH
USW FLEX · GF L-L (Ground)
USW Flex 2.5G 8 PoE
GbE uplink
D16 GroundD3 BetweenD4 Majlis 1D16 Pergola▦ SL GW GF L-L
AP GF L-L
U7 LONG-RANGE
Protection · UDM Pro Security
Edge Defense
✓Honeypot
10 ENTRIES · ACTIVE✓Intrusion Prevention
ENABLED✓Simple App Blocking
CONFIGURED✓Region Blocking · Iran
BLOCK · BOTH✓Encrypted DNS
ACTIVE✓Content Filter · Guest+Staff
ACTIVE · ENFORCEDUSW 2 PRO MAX · Core B
USW Pro Max 24 PoE
10 GbE UPLINK
Hikvision Cameras · FE PoE
D2 Main EntranceD3 PantryD6 Majlis 2D8 Garage 2D9 Garden 1D10 FrontD12 FrontD13 SolarD29 Gym
SuperLink Gateways · FE
▦ SL GW 1F Office▦ SL GW GF Majlis
Direct Access Points
AP GF GYM
U6 IW
AP 1F MASTER BED 1
U7 PRO WALL
AP GF PANTRY
U7 PRO
AP GF MAJLIS
U7 PRO
AP GF THEATRE
U7 PRO
GARDEN
U7 OUTDOOR
AP 1F OFFICE
U7 PRO
USW FLEX · 1F Office
USW Flex 2.5G 8
GbE uplink
Retro NZ · Workstation 2.5G
USW 2F SPA ROOM · 2F Distribution
USW Flex 2.5G 8 PoE
GbE uplink
D15 Pergola▦ SL GW 2F Spa
AP 2F OD PARGOLA
U7 OUTDOOR
AP 2F SPA ROOM
U7 PRO
AP 2F SPA L-L
U6 LR
AP 2F ELEVATOR SHAFT
U7 PRO
AP 2F STORAGE
U6 LR
2F MAINT 1
USW Flex
GbE
D24D25D27
2F MAINT 2
USW Flex
GbE
D21 SPA 1D22 SPA 2D23 SPA 3D26
SuperLink Sensor Mesh · 4 Gateways
Four UniFi SuperLink Gateways distribute wireless sensor coverage across Del Sol Valley — SL GW 1F Office, SL GW 2F Spa, SL GW GF L-L and SL GW GF Majlis. Each gateway is wired to the nearest UniFi switch via Fast Ethernet PoE and bridges battery-powered UP Sense sensors (motion, door, leak, temperature, humidity) into the UniFi Protect ecosystem alongside the two G6 Bullet cameras and 31-channel Hikvision Surveillance VLAN.
Content Filter · Guest VLAN
Basic (Adult & Malicious) · Google · YouTube · Bing
● ACTIVE
→ 192.168.11.0/27
Content Filter · Staff VLAN
Basic (Adult & Malicious) · Google · YouTube · Bing
● ACTIVE
→ 192.168.8.0/27
UniFi Switch
Wi-Fi 7 AP (U7)
Wi-Fi 6 AP (U6)
Hikvision Camera
UP Protect Camera
SuperLink Gateway
VLAN Boundary
KNX Automation
Designed · Deployed · Monitored by QSN
